Gear Drive Rotary Screw Air Compressor CPE-175
Have one to sell?
ConditionNew
New
Experience the innovation and worry-free operation of the Chicago Pneumatic gear drive series of rotary screw air compressors. maintenance produce an environment that lets you focus on your business, not your compressor!
hp 175
acfm @ 100 psig 837
acfm @ 125 psig 806
acfm @ 150 psig 732
acfm @ 175 psig 600
Sound Level (dBa) 75
L x W x H (in) 113 x 59 x 76
Base Weight (lbs) 5732
Low sound enclosure
• 125 psig readily available
• 100, 150 and 175 psig also available
• Wye-delta starter and TEFC motor are standard
• ES4000 Advanced microprocessor control (CPE 100 - 150 HP)
• Airlogic controller (CPF 175-200 HP)
• 230/460V (CPE 100 - 120 HP) and 575V (CPE 100 - 120 HP)
• 460V or 575V (CPE 150 - CPF 200 HP)
•Separate oil and aftercoolers
• Temperature protection on drive side motor bearings (CPE 100 - 120 HP)
• Low sound enclosure
• Side compressed air discharge for easy installation
• Easy access maintenance
• Air/oil sump tank with temperature protection
• Flexible drive coupling (CPF series)
• Improved long life inlet value
• Latest design minimum pressure/oil stop value • Shipped with 8,000 hour lubricant as standard.
