JORDAIR N6-220-3E

System Features:
Balanced Design
Low Noise

Block Features:
Low Oil Consumption
Oil Filter Cartridge
High Tech HP Piston
Heavy Duty Crank

- Logo 8 PLC with panel mounted 4" x 4" TDE 6 line screen showing compressor fault data
- Low oil alarm and screen display of the fault
- High temperature alarm and screen display of the fault
- Final ASCO pressure switch set for customers required shut down pressure Auto-run and manual mode operation with emergency shut down button
- Optional Flexy data modem connection to the customer and service technicians cell phone
- Final drying and oil removal CRN certified filter for 100% oil removal
- Automatic condensate drain and silent collection system
- Panel mounted pressure gauge display for final pressure and oil pressure
- Inter-stage pressure gauges are mounted on the block and visible at the back side of the compressor
- Inlet solenoid and pressure gauge with inlet relief valve
- Nationally certified CRN registered 7300 PSIG final coalescing oil/water separator on 5300
PSIG units with silent collection
- Nationally certified CRN registered 1100 PSIG final coalescing oil/water separator on 580/720 PSIG units with silent colle Final separator cycle counter to ensure filter system safety and record pressure cycles
- The hour meter is mounted on the door of the MCC control box
- The separator pressure cycle counter is mounted on the door of the MCC control box
- Final separator life rated for 35 years or 100,000 pressure cycles
